| No. Of Cylinder | 4 |
| HP Category | 40 HP |
| Capacity CC | 2730 CC |
| Engine Rated RPM | 1900 RPM |
| Cooling | Water Cooled |
| Air Filter | Wet type |
| PTO HP | 36 |
| Fuel Pump | Inline |
| Torque | 158.4 NM |
| Type | Partial Constant Mesh |
| Clutch | Single/Dual clutch |
| Gear Box | 8 Forward + 2 Reverse |
| Battery | 12 V 75 AH |
| Alternator | 12 V 36 A |
| Forward Speed | 2.9 - 29.1 kmph |
| Reverse Speed | 3.9 - 11.2 kmph |
| Brakes | Dry Disc / Oil Immersed ( Optional ) |
| Type | Mechanical/Power Steering (optional) |
| Steering Column | Single Drop Arm |
| Type | CRPTO |
| RPM | 540 |
| Capacity | 48 litre |
| Total Weight | 1785 KG |
| Wheel Base | 1910 MM |
| Overall Width | 1830 MM |
| Lifting Capacity | 1500 kg |
| 3 point Linkage | Draft , Position and Response Control Links |
| Wheel drive | 2 WD |
| Front | 6.00 x 16 |
| Rear | 13.6 x 28 / 12.4 x 28 |
| Accessories | Tools, Top Link |
| Warranty | 2000 Hours Or 2 Year |
| Status | Launched |
